Shiny-advanced

Jie Wang

2023-08-03

Outline

Reactive building blocks
Shiny Modules
golem framework
Wrap-up

Reactive building blocks

There are three fundamental building blocks of reactive programming:

reactive values
reactive expressions
observers

reactive values

Most of the reactive values you’ll encounter will come from the input argument to the server function:

library(shiny)
ui <- fluidPage(
    numericInput(
        "num",
        "Select number of values:",
        value = 5
    ),
    textOutput("t1")
)
server <- function(input, output, session) {
    # we can refer to input$num
    output$t1 <- renderText({
        paste0("You selected ", input$num) # read-only
    })
}

shinyApp(ui, server)

reactive values - reactiveVal()

library(shiny)
reactiveConsole(TRUE)

# set
rv <- reactiveVal(10)

# get
rv()

[1] 10

# set to another value
rv(15)

rv()

[1] 15

reactive values - reactiveValues()

library(shiny)
reactiveConsole(TRUE)

# set
rv <- reactiveValues(x = 10, y = 15)

# get
rv$x

[1] 10

rv$y

[1] 15

# set to another value
rv$x <- 100

rv$x

[1] 100

Combine `reactiveValues` and `observeEvent`

library(shiny)

ui <- fluidPage(
    actionButton("drink", "drink me"),
    actionButton("eat", "eat me"),
    textOutput("notice")
)

server <- function(input, output, session) {
    r <- reactiveValues(notice = "")

    observeEvent(input$drink, {
        r$notice <- "You are no longer thristy"
    })
    observeEvent(input$eat, {
        r$notice <- "You are no longer hungry"
    })
    output$notice <- renderText(r$notice)
}

shinyApp(ui, server)

Exercise 01

library(shiny)
library(ggplot2)
library(dplyr)
library(shinycssloaders)

# a sample data frame
data <- data.frame(
    "category" = c('A', 'B', 'C', 'D'),
    "amount" = c(21, 46, 27, 6)
)

ui <- fluidPage(
    fluidRow(
        column(
            width = 2,
            actionButton(
                "bar",
                "",
                icon = icon("chart-bar")
            ),
            actionButton(
                "pie",
                "",
                icon = icon("chart-pie")
            ),
        ),
        column(
            width = 10,
            plotOutput("p1")
        )
    )
)

server <- function(input, output, session) {
    # complete the server part
}

shinyApp(ui, server)

Exercise 01 - solution

library(shiny)
library(shinycssloaders)
library(dplyr)
library(ggplot2)

# a sample data frame
data <- data.frame(
    "category" = c("A", "B", "C", "D"),
    "amount" = c(21, 46, 27, 6)
)

ui <- fluidPage(
    fluidRow(
        column(
            width = 2,
            actionButton(
                "bar",
                "",
                icon = icon("chart-bar")
            ),
            actionButton(
                "pie",
                "",
                icon = icon("chart-pie")
            ),
        ),
        column(
            width = 10,
            plotOutput("p1") %>%
                withSpinner()
        )
    )
)

server <- function(input, output, session) {
    rv <- reactiveValues(
        plot = NULL
    )

    # bar chart
    observeEvent(input$bar, {
        rv$plot <- ggplot(data, aes(x = category, y = amount, fill = category)) +
            geom_bar(stat = "identity")
    })

    # pie chart
    observeEvent(input$pie, {
        rv$plot <- ggplot(data, aes(x = "", y = amount, fill = category)) +
            geom_bar(stat = "identity", width = 1) +
            coord_polar("y", start = 0)
    })

    output$p1 <- renderPlot({
        rv$plot
    })
}

shinyApp(ui, server)

Exercise 02

library(shiny)

ui <- fillPage(
    plotOutput("plot", click = "click", height = "100%")
)

# Assignment: This app doesn't work! It's supposed to let
# the user click on the plot, and have a data point appear
# where the click occurs. But as written, the data point
# only appears for a moment before disappearing.
#
# This happens because each time the plot is re-rendered,
# the value of input$click is reset to NULL, and thus
# userPoint() becomes NULL as well.
#
# Can you get a single user-added data point to stay?
#
# Bonus points: Can you include not just the single most
# recent click, but ALL clicks made by the user?
#
# Hint: You'll need to replace reactive() with a combo
# of reactiveValues() and observeEvent().

server <- function(input, output, session) {
    # Either NULL, or a 1-row data frame that represents
    # the point that the user clicked on the plot
    userPoint <- reactive({
        # input$click will be either NULL or list(x=num, y=num)
        click <- input$click

        if (is.null(click)) {
            # The user didn't click on the plot (or the previous
            # click was cleared by the plot being re-rendered)
            return(NULL)
        }

        data.frame(speed = click$x, dist = click$y)
    })

    output$plot <- renderPlot({
        # Before plotting, combine the original dataset with
        # the user data. (rbind ignores NULL args.)
        df <- rbind(cars, userPoint())
        plot(df, pch = 19)

        model <- lm(dist ~ speed, df)
        abline(model)
    })
}

shinyApp(ui, server)

Exercise 02 - solution a

library(shiny)

ui <- fillPage(
    plotOutput("plot", click = "click", height = "100%")
)

server <- function(input, output, session) {
    # Instead of a reactive expression for userPoint, we
    # use a reactive value. This gives us more control
    # over when userPoint gets updated.
    rv <- reactiveValues(userPoint = NULL)

    observeEvent(input$click, {
        # Replace rv$userPoint, but only if input$click isn't NULL
        if (!is.null(input$click)) {
            rv$userPoint <- data.frame(
                speed = input$click$x,
                dist = input$click$y
            )
        }
    })

    output$plot <- renderPlot({
        # Now refers to rv$userPoint instead of userPoint().
        df <- rbind(cars, rv$userPoint)
        plot(df, pch = 19)

        model <- lm(dist ~ speed, df)
        abline(model)
    })
}

shinyApp(ui, server)

Exercise 02 - solution b

library(shiny)

ui <- fillPage(
    plotOutput("plot", click = "click", height = "100%")
)

server <- function(input, output, session) {
    rv <- reactiveValues(userPoints = NULL)

    # Same as Solution_05a.R, but instead of keeping
    # track of the single most recent point, we accumulate
    # all previous points using rbind().
    observeEvent(input$click, {
        if (!is.null(input$click)) {
            thisPoint <- data.frame(
                speed = input$click$x,
                dist = input$click$y
            )
            rv$userPoints <- rbind(rv$userPoints, thisPoint)
        }
    })

    output$plot <- renderPlot({
        df <- rbind(cars, rv$userPoints)
        plot(df, pch = 19)

        model <- lm(dist ~ speed, df)
        abline(model)
    })
}

shinyApp(ui, server)

Reactive expressions

those are examples of a “reactive conductor” as they exist in between sources (e.g. an input) and endpoints (e.g. an output).

As such a reactive() depends on various upstream inputs and can be used to generate output.

Their primary use is similar to a function in an R script, they help to

avoid repeating yourself
decompose complex computations into smaller / more modular steps
improve computational efficiency by breaking up / simplifying reactive dependencies

Reactive expressions - example

library(shiny)

ui <- fluidPage(
    numericInput(
        "nsamples",
        "# of samples",
        value = 10
    ),
    verbatimTextOutput("s1"),
    plotOutput("p1")
)
server <- function(input, output, session) {
    output$s1 <- renderPrint({
        summary(rnorm(input$nsamples))
    })

    output$p1 <- renderPlot({
        hist(rnorm(input$nsamples))
    })
}
shinyApp(ui, server)

Reactive expressions - example

What is the problem if we don’t use the reactive() here?

library(shiny)

ui <- fluidPage(
    numericInput(
        "nsamples",
        "# of samples",
        value = 10
    ),
    verbatimTextOutput("s1"),
    plotOutput("p1")
)
server <- function(input, output, session) {
    samples <- reactive(rnorm(input$nsamples))
    output$s1 <- renderPrint({
        summary(samples())
    })

    output$p1 <- renderPlot({
        hist(samples())
    })
}
shinyApp(ui, server)

Reactive expressions - continued

A reactive has two important properties:

it is lazy
it is cached

This means that it only does work when it’s actually needed, and if called twice in a row, it returns the previous value.

Observers and outputs

Observers and outputs differ from reactive expressions in two important ways:

They are eager and forgetful - they run as soon as they possibly can and they don’t remember their previous action
The value returned by an observer is ignored, they are designed to work with functions called for their side-effects

Observers and outputs are powered by the same underlying tool: observe(). This sets up a block of code that is run every time one of the reactive values or expressions it uses is updated.

Observers and outputs - continued

observe() also powers reactive outputs. Reactive outputs are a special type of observers that have two important properties:

They are defined when you assign them into output, e.g. output$p1
They have some limited ability to detect when they are not visible (e.g. non-active tab)

Shiny modules

What are Shiny Modules?

At the simplest level, a module is a pair of UI and server functions.

A piece of a shiny app, that runs inside a shiny application and can represent input, output or both

Why would you use modules?

Create smaller components of a shiny app that can easily be reused in the same app or in other applications
Break up complicated apps for easier reasoning & debugging

https://shiny.rstudio.com/articles/modules.html

Shiny modules have two big advantages:

namespacing makes it easier to understand how your app works because you can write, analyse, and test individual components in isolation
because modules are functions they help you reuse code; anything you can do with a function, you can do with a module.

Shiny module simple example - pre

library(shiny)
ui <- fluidPage(
    selectInput("var", "Variable", names(mtcars)),
    numericInput("bins", "bins", 10, min = 1),
    plotOutput("hist")
)
server <- function(input, output, session) {
    data <- reactive(mtcars[[input$var]])
    output$hist <- renderPlot(
        {
            hist(data(), breaks = input$bins, main = input$var)
        },
        res = 96
    )
}
shinyApp(ui, server)

Shiny module simple example

library(shiny)

histUI <- function(id) {
    ns <- NS(id)
    tagList(
        selectInput(ns("var"), "Variable", choices = names(mtcars)),
        numericInput(ns("bins"), "bins", value = 10, min = 1),
        plotOutput(ns("hist"))
    )
}

histServer <- function(id) {
    moduleServer(id, function(input, output, session) {
        data <- reactive(mtcars[[input$var]])
        output$hist <- renderPlot(
            {
                hist(data(), breaks = input$bins, main = input$var)
            },
            res = 96
        )
    })
}

ui <- fluidPage(
    histUI("hist1")
)
server <- function(input, output, session) {
    histServer("hist1")
}
shinyApp(ui, server)

Namespacing

The key idea that makes modules work is that the name of each control is now determined by two pieces:

The first piece comes from the module user, the developer who calls histUI()
The second piece comes from the module author, the developer who wrote histUI()

# e.g.
# plotOutput(NS(id, "hist"))
id <- "hist1"
chk <- NS(id, "hist")
chk

# e.g.
# plotOutput(ns("hist"))
id <- "hist1"
ns <- NS(id)
ns("hist")
ns("nice")

Exercise 01

library(shiny)

counterButton <- function(id, label = "Counter") {
    # complete the module UI part
    actionButton("button"), label = label),
    verbatimTextOutput("out")
}

counterServer <- function(id) {
    # complete the module server part
    moduleServer(
        id,
        function(input, output, session) {
            count <- reactiveVal(0)
            observeEvent(input$button, {
                count(count() + 1)
            })
        }
    )
}

ui <- fluidPage(
    counterButton("counter1", "Counter #1"),
)

server <- function(input, output, session) {
    counterServer("counter1")
}

shinyApp(ui, server)

Exercise 01 - solution

library(shiny)

counterButton <- function(id, label = "Counter") {
    ns <- NS(id)
    tagList(
        actionButton(ns("button"), label = label),
        verbatimTextOutput(ns("out"))
    )
}

counterServer <- function(id) {
    moduleServer(
        id,
        function(input, output, session) {
            count <- reactiveVal(0)
            observeEvent(input$button, {
                count(count() + 1)
            })
            output$out <- renderText({
                count()
            })
        }
    )
}

ui <- fluidPage(
    counterButton("counter1", "Counter #1"),
    hr(),
    counterButton("counter2", "Counter #2"),
    hr(),
    counterButton("counter3", "Counter #3"),
)

server <- function(input, output, session) {
    counterServer("counter1")
    counterServer("counter2")
    counterServer("counter3")
}

shinyApp(ui, server)

Exercise 02

library(shiny)
library(dplyr)

countButtonUI <- function(id) {
    ns <- NS(id)
    tagList(
        fluidRow(
            column(
                width = 12,
                actionButton(ns("like"), label = "Like: ", icon = icon("thumbs-up"), class = "primary"),
                actionButton(ns("dislike"), label = "Dislike: ", icon = icon("thumbs-down"), class = "primary")
            )
        ),
        fluidRow(
            column(
                width = 12,
                imageOutput(ns("myImage"))
            ),
        )
    )
}

countButtonServer <- function(id, image) {
    moduleServer(
        id,
        function(input, output, session) {
            like_count <- reactiveVal(0)
            observe({
                like_count(like_count() + 1)
            }) %>%
                bindEvent(input$like)

            dislike_count <- reactiveVal(0)
            observe({
                dislike_count(dislike_count() + 1)
            }) %>%
                bindEvent(input$dislike)

            output$myImage <- renderImage(
                {
                    list(
                        src = image,
                        height = "60%",
                        alt = "A pic"
                    )
                },
                deleteFile = FALSE
            )

            observe({
                updateActionButton(
                    inputId = "like", label = paste0("Like: ", like_count()),
                )

                updateActionButton(
                    inputId = "dislike", label = paste0("Dislike: ", dislike_count()),
                )
            })
        }
    )
}

ui <- fluidPage(
    countButtonUI("count1"),
    # add some more gifs
)

server <- function(input, output, session) {
    countButtonServer("count1", image = "hadley.gif")
    # add some more gifs

}

shinyApp(ui, server)

Exercise 02

funnygif

Exercise 02 - solution

library(shiny)
library(dplyr)

countButtonUI <- function(id) {
    ns <- NS(id)
    tagList(
        fluidRow(
            column(
                width = 12,
                actionButton(ns("like"), label = "Like: ", icon = icon("thumbs-up"), class = "primary"),
                actionButton(ns("dislike"), label = "Dislike: ", icon = icon("thumbs-down"), class = "primary")
            )
        ),
        fluidRow(
            column(
                width = 12,
                imageOutput(ns("myImage"))
            ),
        )
    )
}

countButtonServer <- function(id, image) {
    moduleServer(
        id,
        function(input, output, session) {
            like_count <- reactiveVal(0)
            observe({
                like_count(like_count() + 1)
            }) %>%
                bindEvent(input$like)

            dislike_count <- reactiveVal(0)
            observe({
                dislike_count(dislike_count() + 1)
            }) %>%
                bindEvent(input$dislike)

            output$myImage <- renderImage(
                {
                    list(
                        src = image,
                        height = "60%",
                        alt = "A pic"
                    )
                },
                deleteFile = FALSE
            )

            observe({
                updateActionButton(
                    inputId = "like", label = paste0("Like: ", like_count()),
                )

                updateActionButton(
                    inputId = "dislike", label = paste0("Dislike: ", dislike_count()),
                )
            })
        }
    )
}

ui <- fluidPage(
    countButtonUI("count1"),
    hr(),
    countButtonUI("count2"),
    hr(),
    countButtonUI("count3"),
    hr(),
    countButtonUI("count4")
)

server <- function(input, output, session) {
    countButtonServer("count1", image = "hadley.gif")
    countButtonServer("count2", image = "css.gif")
    countButtonServer("count3", image = "programming.gif")
    countButtonServer("count4", image = "refactoring-cat.gif")
}

shinyApp(ui, server)
